1775441-2
Manufacturer:
TE Connectivity
Mfr.Part #:
1775441-2
Datasheet:
Description:
Headers and Wire Housings Wire Receptacle, Socket Number of Positions:2 Pitch:1.4986 mm
| Parameter | Value |
|---|---|
| Length | 4.0894 mm |
| Width | 6.14934 mm |
| Termination | Crimp |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -55 °C |
| Height | 2.70002 mm |
| Packaging | Bulk |
| RoHS | Compliant |
| Pitch | 1.4986 mm |
| Current Rating | 3 A |
| Flammability Rating | UL94 V-0 |
| Orientation | Straight |
| Operating Supply Voltage | 250 V |
| Lifecycle Status | Production (Last Updated: 1 week ago) |
| Color | Natural |
| Number of Contacts | 2 |
| ELV | Compliant |
| Connector Type | Receptacle, Socket |
| Wire/Cable Gauge | 24 AWG |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Housing Material | Thermoplastic |
| Fastening Type | Ramp |
| Connector System | Wire-to-Wire |
| Contact Current Rating | 3 A |
| Housing Color | Natural |
| Contact Gender | Female |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 1 week ago) |
| Sealable | No |
| Mating Retention | With |
Stock: 3714
Distributors
pcbx
pcbxUnit Price$0.15514
Ext.Price$0.15514
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.15514 | $0.15514 |
| 10 | $0.07757 | $0.77570 |
| 50 | $0.07111 | $3.55550 |
| 100 | $0.06518 | $6.51800 |
| 500 | $0.05778 | $28.89000 |
| 1000 | $0.05122 | $51.22000 |
| 3000 | $0.04944 | $148.32000 |
| 5000 | $0.04773 | $238.65000 |
| 10000 | $0.04577 | $457.70000 |
